Description
Centsys Vantage 500 Swing Gate Operators
The Centsys Vantage 500 is a stylish swing gate operator for your larger single and double opening gates. The kit is supplied with 2 actuators, universal mounting brackets (there may be some applications where alternative fixings are required), control box with battery backup and 2 remote controls. It is available in both mains power and solar power options.
FEATURES of the Centsys Vantage 500
- Separate weatherproof housing for dual channel controller, battery and charger.
- Fully sealed plastic housing for controller to prevent ingress of dirt and insects.
- Easy set up of controller using LCD interface.
- Removeable connectors on controller for easy maintenance.
- Watchdog IC ensures full and safe operation of controller.
- Built in multi-channel Nova rolling code receiver with selective deletion of remotes.
- Multiple modes of operation including standard mode, multi-user/condominium mode.
- Full configuration of gate operating parameters including gate speed,ramp-up and ramp-down distances.
- Automatic closing with adjustable time, push button over ride and selectable according to gate status.
- Selectable leaf delay on either gate leaf.
- Advanced positive close mode with short stop.
- Warranty is 24 months return to base, it does not include damages caused by incorrect installation.
